Step 7. Turn the thumbscrew on the front of the controller module anti-clockwise and open the controller
module cover.
1
Thumbscrew
2
Controller module cover
Step 8. Lift out the air duct cover.
62 ThinkSystem DG5000 Hardware Installation and Maintenance Guide
