M.2 adapter and M.2 drive replacement
Use this information to remove and install the M.2 adapter and M.2 drive (an assembled M.2 adapter and M.2
drive is also known as M.2 module).
Remove the M.2 adapter and M.2 drive
Use this information to remove the M.2 adapter and M.2 drive.
About this task
Attention:
• Read Installation Guidelines to ensure that you work safely.
• Power off the server and disconnect all power cords for this task.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-DY1RaWHYM4xDloAwuBQHR0
• Youku: http://list.youku.com/albumlist/show/id_52339628
Procedure
Step 1. Remove the top cover. See Remove the top cover.
