System board replacement
Use this information to remove and install the system board.
S017
CAUTION:
Hazardous moving fan blades nearby.
S012
CAUTION:
Hot surface nearby.
Remove the system board
Use this information to remove the system board.
About this task
A system board, also known as the motherboard, provides different connectors or slots to connect different
components or peripherals of the system for communication. If the system board fails, it must be replaced.
Attention:
• Read Installation Guidelines to ensure that you work safely.
• Power off the server and disconnect all power cords for this task.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-DY1RaWHYM4xDloAwuBQHR0
• Youku: http://list.youku.com/albumlist/show/id_52339628
Procedure
Step 1. Prepare your server.
a. Remove the top cover. See Remove the top cover.
b. If your server comes with an air baffle, remove it first. See Remove the air baffle.
c. If your server comes with a rear drive assembly, remove it first. See Remove the hot-swap rear
drive assembly.
d. Record where the cables are connected to the system board; then, disconnect all the cables.
Chapter 4. Hardware replacement procedures 231
