2.5-inch/3.5-inch drive backplane (signal)
Use the section to understand the cable routing for signal cable connections for 2.5-inch/3.5-inch drive
backplanes.
Your server supports the following server models with:
•
4 x 2.5-inch front drive bays (SAS/SATA)
• 8 x 2.5-inch front drive bays (SAS/SATA)
• 4 x 3.5-inch front drive bays (SAS/SATA)
• 4 x 3.5-inch front drive bays (AnyBay)
• 10 x 2.5-inch front drive bays (AnyBay)
Notes: The 10 x 2.5-inch AnyBay backplane can also be used on the following models:
•
10 x 2.5-inch front drive bays (NVMe)
• 10 x 2.5-inch front drive bays (8AnyBay + 2NVMe)
• 10 x 2.5-inch front drive bays (6SAS/SATA + 4AnyBay)
• 10 x 2.5-inch front drive bays (6SAS/SATA + 4NVMe)
• 10 x 2.5-inch front drive bays (6 SAS/SATA + 2 AnyBay + 2 NVMe)
