Install the security bezel
Use this information to install the security bezel.
About this task
Attention: Read Installation Guidelines to ensure that you work safely.
A video for this task is available at:
• Youtube: https://www.youtube.com/playlist?list=PLYV5R7hVcs-DY1RaWHYM4xDloAwuBQHR0
• Youku: http://list.youku.com/albumlist/show/id_52339628
Procedure
Step 1. If you have removed the rack latches, reinstall them. See Install the rack latches.
Step 2. If the key is held inside the security bezel, remove it out of the security bezel.
Figure 121. Key removal
Step 3. Carefully insert the tab on the security bezel into the slot on the right rack latch. Then, press and
hold the blue release latch and rotate the security bezel inward until the other side clicks into place.
Figure 122. Security bezel installation
Chapter 4. Hardware replacement procedures 229
