Wiring the standard device
Wiring of the feedback system
Important notes
5
5.11
5.11.1
5.11-1
EDSVF9333V EN 3.0-06/2005
5.11 Wiring of the f eedback system
5.11.1 Important notes
ƒ An incremental encoder can be connected to input X8 or input X9:
– Incremental encoder with TTL level are connected to X8.
– Incremental encoder with HTL level are connected to X9.
ƒ The incremental encoder signal can be output at the master frequency
output X10 for slave drives.
Note!
ƒ Lenze recommends using Lenze system cables for wiring.
ƒ If self-prepared cables are used, only use cables with cores that
are twisted in pairs and shielded.
Installation material required from the scope of supply:
Description Use Amount
Protective cover Protection for unused Sub-D sockets 4
