Technical data
General data/operating conditions
3
3.1
3.1-2
EDSVF9333V EN 3.0-06/2005
Field Values
EMC Compliance with EN 61800-3/A11
Noise emission Requirements according to EN 50081-2, EN 50082-1,
IEC 22G-WG4 (Cv) 21
Compliance with the limit class A according to EN 55011
(industrial premises) using mains filter A
Compliance with the limit class B according t o EN 55022
(residential area) using mains filter B and installation in control
cabinet
Noise immunity
Requirements according to EN 61800-3 incl. A11
Requirements Standard Severities
ESD 61000
DXRA090-4-2
3, i. e. 8 kV for air
discharge
6kVwithcontact
discharge
Cable-guided high
frequency
61000
DXRA090-4-6
150 kHz ... 80 MHz, 10
V/m 80 % AM (1 kHz)
RF interference
(Housing)
61000
DXRA090-4-3
80 MHz ... 1000 MHz, 10
V/m 80 % AM (1 kHz)
Burst 61000
DXRA090-4-4
3/4, i. e. 2 kV/5 kHz
Surge
(Surge on mains
cable)
61000
DXRA090-4-5
3, i. e. 1.2/50 μs,
1 kV phase-phase, 2
kV phase-PE
Insulation resistance Overvoltage category III to VDE 0110
Discharge current against
PE (to EN 50178)
>3.5mA
Enclosure
IP20
Shock protection to NEMA 250 type 1
Protection measures
against
Shortcircuit,earthfault(earth-faultprotectedduringmains
connection, limited earth-fault protection during mains
connection), overvoltage, motor stalling, motor overtemperature
(input for PTC or thermal contact)
Protective insulation of
control circuits
Safe mains isolation: Double/reinforced insulation according to
EN 50178 for digital inputs and outputs
Permissible supply forms
OperationonTTsystems,TNsystemsorsystemswithearthed
neutral without additional measures
Operation on IT systems only with variant ”V024” or ”V100”
General electrical data
