Configuration
Function blocks
Internal motor control with V/f characteristic control (MCTRL1)
8
8.2
8.2.6
8.2-32
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0904
cfg: DC-BREAK 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block MCTRL
z HIGH = Motor is braked
8.2-25
8.2-48
C0905 DIS: DC-BREAK 0 1 Function block MCTRL
z Display of the signal linked in
C0904
C0906 -199.99 {0.01 %} 199.99
Function block MCTRL
z Display of the signals linked in
C0890, C0891, C0892, C0893,
C0901 and C0903
8.2-25
8.2-48
1 DIS: N-SET
2 DIS: M-ADD
3 DIS: LO-M-LIM
4 DIS: HI-M-LIM
5 DIS: I-SET
6 DIS: BOOST
C0907 0 1
Function block MCTRL
z Display of the signals linked in
C0899, C0900 and C0902
1 reserved
2 DIS: N/M-SWT
3 DIS: QSP
4 DIS: I-LOAD
C0909 speed limit 1
1 +/- 175 %
Speed limitation, function block
MCTRL
z Limitation of direction of
rotation for the speed setpoint
8.2-25
8.2-48
2 0 ... 175 %
3 -175 ... 0 %
C0910
CFG: VP-ADAPT 1006 FIXED100% Selection list 1 Configuration of analog input
signal, function block MCTRL
z Gain adaptation of the speed
controller
z If the gain is varying, join to
CURVE-OUT of FB CURVE
8.2-25
8.2-48
C0911 DIS: VP-ADAPT -199.99 {0.01 %} 199.99 Function block MCTRL
z Display of the signal linked in
C0910
C0912 OV delay time Æ - {1 ms} - Delay time of the pulse release
after an OU message
Æ depending on C0082, C0086,
C0087, C0088, C0089, C0090,
C0091, C0092
A change of one of the codes
resets C0912 to the time of the
selected motor
z Thetimeisderivedfromthe
double rotor time constant
8.2-25
8.2-48
9.4-3
C0913
OV handling 0 Value of the motor current during
the flying restart process or after
an OU message
z When C0913 = 1, the motor is
driven with reduced current to
the setpoint speed during the
flying restart process of after an
OU message.
z The setting is only effective for
the drives EVF9326 ... EVF9333
8.2-25
8.2-48
0 inactive Non-reduced motor current
1 active Reduced motor current
