Lenze 9300 vector Series User Manual

Commissioning
Optimising the operating behaviour
Motor magnetising current with vector control
6
6.11
6.11.4

6.11-10
EDSVF9333V EN 3.0-06/2005
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0080 Vp field C TRL 0.00 0.00 {0.01 } 0.99 Influence on the motor
magnetising current set in C0095
z Not effective when C0006 = 1
andC0025>1
z Sphere of influence is effective
from 0 Hz to the frequency set
in C1583
 6.6-1
 6.11-5
C0095

Mot Io Æ 0.00 {0.01 A} 1000.00 Motor magnetising current
Æ depending on C0086, C0088
and C0091
z Change of C0086, C0088 and
C0091 sets C0095 to the Lenze
setting
z Change of C0095 sets
C0086 = 0
 6.6-1
 6.11-5
C1583 fset high 100.0
0
0.00 {0.01 %} 199.99 Adaptation of the motor
magnetising current set in C0095
(with V/f characteristic control:
influence limit of the boost
correction; with vector control:
influence limit of the field
precontrol)
z The output frequency is set up
to which the motor
magnetising current set in
C0095 is to have an effect.
z C1583 = 100 % ≙ half the
rated motor frequency in
C0089
 6.11-5
