Selection list 3: Phase signals
8
8.4
8.4.3
8.4-6
EDSVF9333V EN 3.0-06/2005
Parameter Digital output signal ()
020400 CAN-SYNC-OUT
025001
AIF-CTRL.B0
025002 AIF-CTRL.B1
025003 AIF-CTRL.B2
025005 AIF-CTRL.B4
025006 AIF-CTRL.B5
025007 AIF-CTRL.B6
025008 AIF-CTRL.B7
025013 AIF-CTRL.B12
025014 AIF-CTRL.B13
025015 AIF-CTRL.B14
025016 AIF-CTRL.B15
025101 AIF-IN.B0
025102 AIF-IN.B1
025103 AIF-IN.B2
025104 AIF-IN.B3
025105 AIF-IN.B4
025106 AIF-IN.B5
025107 AIF-IN.B6
025108 AIF-IN.B7
025109 AIF-IN.B8
025110 AIF-IN.B9
Parameter Digital output signal ()
025111 AIF-IN.B10
025112
AIF-IN.B11
025113 AIF-IN.B12
025114 AIF-IN.B13
025115 AIF-IN.B14
025116 AIF-IN.B15
025117 AIF-IN.B16
025118 AIF-IN.B17
025119 AIF-IN.B18
025120 AIF-IN.B19
025121 AIF-IN.B20
025122 AIF-IN.B21
025123 AIF-IN.B22
025124 AIF-IN.B23
025125 AIF-IN.B24
025126 AIF-IN.B25
025127 AIF-IN.B26
025128 AIF-IN.B27
025129 AIF-IN.B28
025130 AIF-IN.B29
025131 AIF-IN.B30
025132 AIF-IN.B31
8.4.3 Selection list 3: Phase signals
Parameter Phase signal ()
000100 DFSET-PSET
001000
FIXED0INC
005000 MCTRL-PHI-ANG
011100 INT1-POUT
011105 INT2-POUT
Parameter Phase signal ()
019521 FCODE-474/1
019522
FCODE-474/2
020103 CAN-IN1.D1
020201
CAN-IN2.D1
020301 CAN-IN3.D1
025103 AIF-IN.D1
8.4.4 Selection list 4: Speed signals
Parameter Speed signal ()
000050 DFIN-OUT
000100
DFSET-POUT
000250 DFOUT-OUT
001000 FIXEDPHI-0
Parameter Speed signal ()
005000 MCTRL-PHI-ACT
006000
DFRFG-OUT
006220 CONV5-OUT
019521 FCODE-475/1
019522 FCODE-475/2
