Lenze 9300 vector Series User Manual

Configuration
Code table
8
8.3

8.3-67
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C1336 Tir overlay 1.0 0.1 {0.1 s} 6000.0 Fade-in time, function block
PCTRL2
z Acceleration time of the ramp
generator
z Controls the influence of the
process controller
See System
Manual
(extension)
C1337 Tif overlay 1.0 0.1 {0.1 s} 6000.0 Fade-out time, function block
PCTRL2
z Deceleration time of the ramp
generator
z Controls the influence of the
process controller
C1340

 Selection list 1 Configuration of analog input
signals, function block PCTRL2
See System
Manual
(extension)
1 CFG: RFG-SET 1000 FIXED0% z The process setpoint is shown
at PCTRL2-SET with a starting
value via a ramp generator
z PCTRL-RFG-LOAD = HIGH
activates the function
2 CFG: SET 1000 FIXED0% z Input for process value
z Value range: ±200 %
3 CFG: ACT 1000 FIXED0% z Input for actual value
z Value range: ±200 %
4 CFG: INFL 1000 FIXED0% z Evaluation (influence) of the
output signal
z Value range: ±200 %
C1341

 Selection list 2 Configuration of digital input
signals, function block PCTRL2
See System
Manual
(extension)
1 CFG: RFG-LOAD 1000 FIXED0 z HIGH = function of
PCTRL2-RFG-SET is active
2 CFG: I-OFF 1000 FIXED0 z HIGH = Switches of integral
action component
z LOW = switches on integral
action component
3 CFG: INACT 1000 FIXED0 z HIGH = deactivates process
controller
4 CFG: OVERLAY 1000 FIXED0 z HIGH = Shows influence
z LOW = hides influence
C1344 -199.99 {0.01 %} 199.99
Function block PCTRL2
z Display of the signals linked in
C1340
See System
Manual
(extension)
1 DIS: RFG-SET
2 DIS: SET
3 DIS: ACT
4 DIS: INFL
C1345 0 1
Function block PCTRL2
z Display of the signals linked in
C1341
1 DIS: RFG-LOAD
2 DIS: I-OFF
3 DIS: INACT
4 DIS: OVERLAY
C1350 INT1 function 0
Function selection, function block
INT1
See System
Manual
(extension)
0 PHI >= REF If INT1-IN ≥ INT1-REF, INT1-DOUT
is set to HIGH
1 |PHI| >= |REF| If |INT1-IN| ≥ |INT1-REF|,
INT1-DOUT is set to HIGH
C1351 INT1 scaling 65536
00
65536 {1} 1000000000
Scaling factor, function block
INT1
INT1 − AOUT [%] =
INT1 − IN [inc]
C1351
⋅ 100 %
