Configuration
Code table
8
8.3

8.3-55
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0858 -199.99 {0.01 %} 199.99
Process output words, function
block AIF-OUT
z Display of the signals linked in
C0850
z 100% = 16384
See System
Manual
(extension)
1 DIS: OUT.W1
2 DIS: OUT.W2
3 DIS: OUT.W3
C0859 DIS: OUT.D1 -2147483648 {1} 2147483647 32-bit phase signal, function
block AIF-OUT
z Display of the signal linked in
C0851
z 1 rev. = 65536
See System
Manual
(extension)
C0860

 Selection list 1 Configuration of analog input
signals, function block CAN-OUT
See System
Manual
(extension)
1 CFG: OUT1.W1 1000 FIXED0%
CAN-OUT1
2 CFG: OUT1.W2 1000 FIXED0%
3 CFG: OUT1.W3 1000 FIXED0%
4 CFG: OUT2.W1 1000 FIXED0%
5 CFG: OUT2.W2 1000 FIXED0%
CAN-OUT2
6 CFG: OUT2.W3 1000 FIXED0%
7 CFG: OUT2.W4 1000 FIXED0%
8 CFG: OUT3.W1 1000 FIXED0%
CAN-OUT3
9 CFG: OUT3.W2 1000 FIXED0%
10 CFG: OUT3.W3 1000 FIXED0%
11 CFG: OUT3.W4 1000 FIXED0%
C0861

 Selection list 3 Configuration of input signals,
function block CAN-OUT
1 CFG: OUT1.D1 1000 FIXED0INC CAN-OUT1
2 CFG: OUT2.D1 1000 FIXED0INC CAN-OUT2
3 CFG: OUT3.D1 1000 FIXED0INC CAN-OUT3
C0863 0 FFFF Process input words, function
block CAN-IN
z Read only
z Bit0...bit15(viabyte5and
byte 6)
z Bit 16 ... bit 31 (via byte 7 and
byte 8)
See System
Manual
(extension)
1 DIS: IN1 dig0 CAN-IN1, bit 0 ... bit 15
2 DIS: IN1 dig16 CAN-IN1, bit 16 ... bit 31
3 DIS: IN2 dig0 CAN-IN2, bit 0 ... bit 15
4 DIS: IN2 dig16 CAN-IN2, bit 16 ... bit 31
5 DIS: IN3 dig0 CAN-IN3, bit 0 ... bit 15
6 DIS: IN3 dig16 CAN-IN3, bit 16 ... bit 31
