Wiring the standard device
Wiring of digital frequency input / digital frequency output
5
5.12
5.12-1
EDSVF9333V EN 3.0-06/2005
5.12 Wiring of digital frequency input / digital frequency output
Installation material required from the scope of supply:
Description Use Amount
Protective cover Protection for unused Sub-D sockets 4
Field Master frequency output X10
Connection at drive controller 9-pole Sub-D socket
Pin assignment Dependent on the selected basic configuration
Output frequency 0 ... 500 Nm
Signal Two-track with inverse 5 V signals (RS422) and zero track
Load capacity Maximum 20 mA per channel
(up to 3 slave drives can be connected)
Special features The ”Enable” output signal at X10/8 switches to LOW if the
drive controller is not ready for operation (e.g. separated from
mains). This may trip SD3 monitoring at the slave drive.
Internal voltage source
(X10/4, X10/5)
DC5V/max.50mA
Total current at X9/4, X9/5 and X10/4, X10/5: max. 200 mA
Field Master frequency input X9
Connection at drive controller 9-pole Sub-D socket
Input frequency TTL level: 0 ... 500 kHz
HTL level: 0 ... 200 kHz
Signal Two-track with inverse signals and zero track
Single-track without inverse signals and zero track (only for
HTL level)
Signal evaluation Via code C0427
Current consumption Maximum 5 mA
Special features With activated SD3 monitoring, TRIP or warning is tripped if
the ”Lamp Control” input signal at X9/8 switches to LOW.
This may cause the drive controller to respond if the master
drive is not ready for operation.
Technical data
