Function block library
7-213

SHB9300CRV EN 2.0
SRFG1-IN
SRFG1-O UT
t
t
t
t
C 1040
C 1040
C 1041
SRFG 1-D IFF
(A cceleration)
Fig. 7-175 Line diagram
l
Max. acceleration:
– For the positive as well as for the negative acceleration, C1040 applies.
– The setting is calculated according to the formula:
T
ir lin
 1s ô
W
2
[%]  W
1
[%]
C1040 [%]
W2
t [s ]
n [% ]
W1
T
ir lin
K35.0272
l Jolt (C1041):
– The jolt is entered in [s] until the ramp generator operates with maximum acceleration (see
Fig. 7-175).
