Configuration
7-282
SHB9300CRV EN 2.0
Operating level
Change from the prameter level to the operating level by pressing PRG.
l
The operating level indicates additional status information or displays the additional display
value determined under C0004 (presetting: act. speed C0051).
– In the USER menu the first line indicates the first code of the USER menu.
l
The additional information is indicated according to the following priority list:
Priority Display Meaning
1 GLOBAL DRIVE INIT Initialization or communication fault between keypad and controller
2 XXX - TRIP Active TRIP (contents of C0168/1)
3 XXX - MESSAGE Active message (contents of C0168/1)
4
Special controller status:
Switch-on inhibit
5
Source for controller inhibit (at the same time value of C0004 is displayed):
STP1 Te rmina l X5 /2 8
STP3 Keypad or LECOM A/B/LI
STP4 InterBus-S or Profibus
STP5 System bus (CAN)
STP6 C0040
6
Source for quick stop:
QSP-term-Ext Input MCTRL-QSP at function block MCTRL is at HIGH signal
(factory setting: assigned to terminals X5/E1 and X5/E2)
QSP-C0135 Keypad or LECOM A/B/LI
QSP-AIF InterBus-S or Profibus
QSP-CAN System bus (CAN)
7 XXX - WARNING Active warning (contents of C0168/1)
8 xxxx Value of C0004
User menu
In practical use it might be necessary to change certain codes more than once.
Under C0517 it is therefore possible to install a user menu with max. 32 codes which are to be
changed most frequently.
l
The number before the comma is the code number.
l
The number after the comma stands for the subcode.
l
Code-subcode combinations must only occur once.
