Lenze 9325 - Page 447

Configuration
7-326

SHB9300CRV EN 2.0
Selection list 3, signals (▲) Selection list 4, signals (
D
) Selection list 5, function blocks
000100 DFSET-PSET 000050 DFIN-OUT 000000 empty 010570 OR5
000101 DFSET-PSET2 000100 DFSET-POUT 000050 AIN1 010600 NOT1
001000 FIXED0INC 000250 DFOUT-OUT 000055 AIN2 010605 NOT2
005000 MCTRL-PHI-ANG 001000 FIXEDPHI-0 000070 AOUT1 010610 NOT3
005200 REF- PSET 005000 MCTRL-PHI-ACT 000075 AOUT2 010615 NOT4
005520 ARITPH1-OUT 006000 DFRFG-OUT 000100 DFSET 010620 NOT5
005580 PHADD1-OUT 006220 CONV5-OUT 000200 DFIN 010650 CMP1
006235 CONVPHPH1-OUT 006230 CONVPHA1-OUT2 000250 DFOUT 010655 CMP2
012000 PHINT1-OUT 006240 CONVPP1-OUT 005050 NSET 010660 CMP3
012005 PHINT2-OUT 013301 CDATA-NOUT 005100 MPOT1 010680 PHCMP1
012050 PHDIV1-OUT 013302 CDATA-N-SYNCH 005150 PCTRL1 010685 PHCMP2
013301 CDATA-LEN1 013312 CURVEC1-DFOUT 005200 REF 010700 DIGDEL1
013302 CDATA-LEN2 013400 YSET1-OUT 005500 ARIT1 010705 DIGDEL2
013303 CDATA-LEN3 013501 CERR1-W-LIM 005505 ARIT2 010750 TRANS1
013304 CDATA-LEN4 013551 CLUT-NSET 005505 ARITPH1 010755 TRANS2
013305 CDATA-LEN5 013701 MSEL1-OUT 005550 ADD1 010900 FLIP1
013306 CDATA-ACTLEN 013851 CONVPHD1-OUT 005580 PHADD1 010905 FLIP2
013307 CDATA-XPOS 013911 CONVPHPHD1-OUT 005600 RFG1 012000 PHINT1
013308 CDATA-YOUT 014441 SWPHD1-OUT 005610 SRFG1 012005 PHINT2
013309 CDATA-YEND 014445 SWPHD2-OUT 005650 ASW1 012050 PHDIV1
013312 CURVEC1-OUT 019521 FCODE-475/1 005655 ASW2 013000 FEVAN1
013351 CCTRL-POUT 019522 FCODE-475/2 005700 ANEG1 014000 PHDIFF1
013352 CCTRL-PHI-SET 005705 ANEG2 014050 STORE1
013353 CCTRL-PHI-ACT 005750 FIXSET1 014055 STORE2
013354 CCTRL-PHI-SET2 005800 LIM1 014100 GEARCOMP
013501 CERR1-ERR 005850 ABS1 020000 CAN-OUT
013502 CERR1-WARN 005900 PT1-1 025000 AIF-OUT
013551 CLUT-O-POS 005950 DT1-1
013651 PSAVE-M-DIFF 006000 DFRFG1
013652 PSAVE-M-SAVE 006100 MFAIL
013653 PSAVE-ACT-DIFF 006150 DB1
013654 PSAVE-ACT-SAVE 006200 CONV1
013711 MSEL2-OUT 006205 CONV2
013751 WELD-XOUT 006210 CONV3
013951 RFGPH1-OUT 006215 CONV4
014000 PHDIFF1-OUT 006220 CONV5
014050 STORE1-PHACT 006300 S&H1
014051 STORE1-PH1 006350 CURVE1
014052 STORE1-PH2 006400 FCNT1
014053 STORE1-PHDIFF 010000 BRK1
014055 STORE2-PHACT 010250 CW/CCW/Q
014056 STORE2-PH1 010500 AND1
014057 STORE2-PH2 010505 AND2
014100 GEARCOMP-OUT 010510 AND3
019521 FCODE-474/1 010515 AND4
019522 FCODE-474/2 010520 AND5
020103 CAN-IN1.D1 010550 OR1
020201 CAN-IN2.D1 010555 OR2
020301 CAN-IN3.D1 010560 OR3
025103 AIF-IN.D1 010565 OR4
