Installation
4-35
 SHB9300CRV EN 2.0
K1
K1
L3
N
PE
L1
L2
U V
W
M
3~
PE
PE
L1 L2 L3
K1
F1 ... F3
932X - 933X
+UG -UG
+UG
-UG
9351
A3 28
E1E2E3E4E5
A1
A2
59
39
A4
+
123
4
763
+
7
62
Z1
-X1
Z2
K1
OFF
ON
RFR
RB
T1
T2
R
X7
F4 F5
K35.0124
PES
PES
PES
PES
PES
PES
PES
PES
PES
PES
PE
PE
PE
Fig. 4-17 Example for wiring in accordance with the EMC regulations
F1...F5 Protection, see “Cable protection” (
& 3-6
) / “mains connection” (
& 4-13
)
K1 Mains contactor
Z1 Mains filter “A” or “B” see Accessories.
Z2 Brake module, see Accessories.
-X1 Terminal strip in control cabinet
PES RF scree termination by a PE connection with a surface as large as possible (see ”Screening” in
this chapter).
