Code table
10
Function library
10.20
L
10.20-18
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0155
*
Extended status
Bit Assignment
word
0 not ready for operation (NOT DCTRL-RDY)
1 not assigned
2 I
max
(MCTRL1-IMAX)
3 Pulse inhibit (DCTRL1-IMP)
4 not assigned
5 Controller inhibit (DCTRL1-CINH)
6 TRIP (DCTRL1-TRIP)
7 not assigned
8 Collective message
(DCTRL1-OH-PTC-LP1-FAN1-WARN)
9 PAR B0 (DCTRL1-PAR-B0)
10 PAR B1 (DCTRL1-PAR-B1)
11 ... 15 Reserved
C0156* Current t hreshold 0 0 {1 %} 150 Programmable current threshold
• Reference: Rated controller current
• Signal output configuration under C0008
or C0415
• The reference values for vector control
and sensorless speed control can be
changed under C0311 (as of soft ware
version 3.1).
C0161* Active error
Display history buffer contents ^ 11.1-1
C0162* Last fault
p
y
y
• Keypad: three-digit, alpha numerical
f
a
u
l
t
d
e
t
e
c
t
i
o
n
C0163* Last but one f ault
fault detection
•
9
3
7
1
B
B
k
e
y
p
a
d
:
L
E
C
O
M
f
a
u
l
t
n
u
m
b
e
r
C0164* Last but two fault
•
9
3
7
1
B
B
k
eypa
d
:
L
E
C
O
M
f
au
l
t
num
b
er
C0165 Service code
LECOM
Modifications only by Lenze Service!
C0168* Actual fault History buffer displays ”active error”
• Keypad: three-digit, alpha numerical
fault detection
• 9371BB keypad: LECOM f ault number
^ 11.1-1
C0170
v
Configuration TRIP
reset
0
0 TRIP reset by mains switching, s, LOW–signal
at X3/28, via function module or communication
module
• TRIP reset via function module or
communication mo dule with C0043,
C0410/12 o r C0135 bit 11.
^ 11.5-1
1 like 0 and additional auto TRIP reset
• Auto TRIP reset after the time set under
C
0
1
7
1
2 TRIP reset through mains switching, via function
module or communication module
C0171.
3 TRIP reset by mains switching
C0171 Delay for auto-TRIP
reset
0.00 0.00 {0.01 sec} 60.00
C0174* Brake transistor 100
78 {1 %} 110
Only active with 8200 vect or 0.55 ... 11 ^ 13.4-1
s
threshold
Recommended setting
y
kW, variant for 400/500 V mains voltage
•
1
0
0
%
T
h
r
e
s
h
o
l
d
D
C
7
9
0
V
U
mains
[3/PE AC xxx V]
380
400
415
440
460
480
500
C0174
[%]
78
81
84
89
93
97
100
U
DC
[V DC]
618
642
665
704
735
767
790
• 100 % = Threshold DC 790
V
• 110 % = Brake transistor switched off
• U
DC
= Threshold in V DC
• The recommended setting allows max.
10 % mains overvoltage
C0178* Operating t ime {h} Only display
Total duration terminal 28 (CINH) = HIGH
C0179* Power-on time {h} Only display
Total time mains on
