Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x231F:001
(P500.01)
Module ID: Acve module ID
(Module ID: Acve module ID)
•
Read only
Display of the network opons currently congured in the inverter.
•
With the help of this module ID, the keypad only shows the communi-
caon parameters relevant to the respecve network.
Note!
When switched on, the inverter checks whether the parameter sengs
saved in the memory module match the inverter hardware and rm-
ware. In case of an incompability, a corresponding error message is
output. For details see chapter "Data handling" (secon "Hardware and
rmware updates/downgrades"). ^ 92
48 No network
67 CANopen
87 Modbus
0x231F:002
(P500.02)
Module ID: Module ID connected
(Module ID: Module ID conn.)
•
Read only
•
For the meaning of the display see parameter
0x231F:001 (P500.01). ^ 175
Display of the network opon currently available in the inverter.
Note!
When switched on, the inverter checks whether the parameter sengs
saved in the memory module match the inverter hardware and rm-
ware. In case of an incompability, a corresponding error message is
output. For details see chapter "Data handling" (secon "Hardware and
rmware updates/downgrades"). ^ 92
0x400E:001
(P505.01)
NetWordIN1 funcon: Bit 0
(NetWordIN1 fct.: NetWordIN1.00)
•
Seng can only be changed if the inverter is inhibi-
ted.
Denion of the funcon that is to be triggered via bit 0 of the mappa-
ble NetWordIN1 data word.
0 Not acve Trigger bit without any funcon.
1 Disable inverter Trigger bit = 0-1 edge: The inverter is disabled.
Trigger bit = 0: The inverter is enabled (unless there is another cause for
inverter disable).
Notes:
•
In all device states, a 0-1 edge causes an immediate change to the
inhibited state with one excepon: If the inverter is in the error status
and the error condion sll exists, the inverter remains in the error
status.
•
Changing to the disabled state causes an immediate stop of the
motor, regardless of the stop method set in 0x2838:003 (P203.03).
The motor coasts down as a funcon of the mass inera of the
machine.
•
In the disabled state, the motor cannot be started.
•
Aer the inverter disable is deacvated, a renewed start command is
required to restart the motor.
•
The cause(s) that are acve for the disabled state are shown in
0x282A:001 (P126.01).
2 Stopping Trigger bit = 1: Motor is stopped.
Trigger bit = 0: No acon / Deacvate stop again.
Notes:
•
The stop method can be selected in 0x2838:003 (P203.03).
3 Acvate quick stop Trigger bit = 1: "Quick stop" funcon acvated.
Trigger bit = 0: no acon / deacvate funcon again.
Notes:
•
The "Quick stop" funcon brings the motor to a standsll within the
deceleraon me set in 0x291C (P225.00).
•
The "Quick stop" funcon has a higher priority than the "Run" func-
on.
4 Reset error Trigger bit = 0-1 edge: Acve error is reset (acknowledged) if the error
condion is not acve anymore and the error is reseable.
Trigger bit = 0: No acon.
Notes:
•
Aer reseng the error, a new enable/start command is required to
restart the motor.
4Error handling ^ 90
5 Acvate DC braking Trigger bit = 1: "DC braking" funcon acvated.
Trigger bit = 0: no acon / deacvate funcon again.
4DC braking ^ 268
Conguring the network
General network sengs
175
