Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x400E:011
(P505.11)
NetWordIN1 funcon: Bit 10
(NetWordIN1 fct.: NetWordIN1.10)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x400E:001 (P505.01). ^ 175
Denion of the funcon that is to be triggered via bit 10 of the mappa-
ble NetWordIN1 data word.
0 Not acve
0x400E:012
(P505.12)
NetWordIN1 funcon: Bit 11
(NetWordIN1 fct.: NetWordIN1.11)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x400E:001 (P505.01). ^ 175
Denion of the funcon that is to be triggered via bit 11 of the mappa-
ble NetWordIN1 data word.
0 Not acve
0x400E:013
(P505.13)
NetWordIN1 funcon: Bit 12
(NetWordIN1 fct.: NetWordIN1.12)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x400E:001 (P505.01). ^ 175
Denion of the funcon that is to be triggered via bit 12 of the mappa-
ble NetWordIN1 data word.
13 Reverse rotaonal direcon
0x400E:014
(P505.14)
NetWordIN1 funcon: Bit 13
(NetWordIN1 fct.: NetWordIN1.13)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x400E:001 (P505.01). ^ 175
Denion of the funcon that is to be triggered via bit 13 of the mappa-
ble NetWordIN1 data word.
0 Not acve
0x400E:015
(P505.15)
NetWordIN1 funcon: Bit 14
(NetWordIN1 fct.: NetWordIN1.14)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x400E:001 (P505.01). ^ 175
Denion of the funcon that is to be triggered via bit 14 of the mappa-
ble NetWordIN1 data word.
0 Not acve
0x400E:016
(P505.16)
NetWordIN1 funcon: Bit 15
(NetWordIN1 fct.: NetWordIN1.15)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x400E:001 (P505.01). ^ 175
Denion of the funcon that is to be triggered via bit 15 of the mappa-
ble NetWordIN1 data word.
0 Not acve
0x2631:001
(P400.01)
Funcon list: Enable inverter
(Funcon list: Enable inverter)
•
Seng can only be changed if the inverter is inhibi-
ted.
Assignment of a trigger for the "Enable inverter" funcon.
Trigger = TRUE: The inverter is enabled (unless there is another cause for
inverter disable).
Trigger = FALSE: The inverter is disabled.
Notes:
•
This funcon must be set to TRUE to start the motor. Either via an
assigned digital input or by default seng "Constant TRUE [1]".
•
Changing to the inhibited state causes an immediate stop of the
motor, regardless of the stop method set in 0x2838:003 (P203.03).
The motor becomes torqueless and coasts down as a funcon of the
mass inera of the machine.
•
The cause(s) that are acve for the disabled state are shown in
0x282A:001 (P126.01).
0 Not connected No trigger assigned (trigger is constantly FALSE).
1 Constant TRUE Trigger is constantly TRUE.
11 Digital input 1 State of X3/DI1, taking an inversion set in 0x2632:001 (P411.01) into
consideraon.
12 Digital input 2 State of X3/DI2, taking an inversion set in 0x2632:002 (P411.02) into
consideraon.
13 Digital input 3 State of X3/DI3, taking an inversion set in 0x2632:003 (P411.03) into
consideraon.
Conguring the network
General network sengs
180
