Lenze i510 Series - Page 184

Parameter Name / value range / [default seng] Info
0x2631:017
(P400.17)
Funcon list: Acvate network setpoint
(Funcon list: Setp: Network)
•
From version 02.01
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate network setpoint" funcon.
Trigger = TRUE: the network is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no acon / deacvate funcon again.
0 Not connected
116 Network setpoint acve (from version 02.00) TRUE if a change-over to network setpoint is requested via bit 6 of the
AC drive control word0x400B:001 (P592.01). Otherwise FALSE.
Notes:
•
Set this selecon if the network setpoint is to be acvated via bit 6 of
the AC drive control word.
•
The AC drive control word can be used with any communicaon pro-
tocol.
4AC Drive Prole ^ 193
0x2631:037
(P400.37)
Funcon list: Acvate network control
(Funcon list: Network control)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate network control" funcon.
Trigger = TRUE: Acvate network control.
Trigger = FALSE: No acon / deacvate network control again.
0 Not connected
114 Network control acve (from version 02.00) TRUE if the network control is requested via bit 5 of the AC drive control
word 0x400B:001 (P592.01). Otherwise FALSE.
Notes:
•
Set this selecon if the network control is to be acvated via bit 5 of
the AC drive control word.
•
The AC drive control word can be used with any communicaon pro-
tocol.
4AC Drive Prole ^ 193
0x2631:043
(P400.43)
Funcon list: Acvate fault 1
(Funcon list: Fault 1)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate fault 1" funcon.
Trigger = TRUE: Trigger user-dened error 1.
Trigger = FALSE: no acon.
Notes:
•
Aer the error is triggered, the motor is brought to a standsll with
the quick stop ramp. The inverter is then disabled.
Associated error code:
•
25217 | 0x6281 - User-dened fault 1
0 Not connected
0x2631:044
(P400.44)
Funcon list: Acvate fault 2
(Funcon list: Fault 2)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate fault 2" funcon.
Trigger = TRUE: Trigger user-dened error 2.
Trigger = FALSE: no acon.
Notes:
•
Aer the error is triggered, the motor is brought to a standsll with
the quick stop ramp. The inverter is then disabled.
Associated error code:
•
25218 | 0x6282 - User-dened fault 2
0 Not connected
0x2634:010
(P420.10)
Digital outputs funcon: NetWordOUT1 - bit 0
(Dig.out.funcon: NetWordOUT1.00)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 415
Assignment of a trigger to bit 0 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
51 Ready for operaon
0x2634:011
(P420.11)
Digital outputs funcon: NetWordOUT1 - bit 1
(Dig.out.funcon: NetWordOUT1.01)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 415
Assignment of a trigger to bit 1 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0 Not connected
0x2634:012
(P420.12)
Digital outputs funcon: NetWordOUT1 - bit 2
(Dig.out.funcon: NetWordOUT1.02)
•
For further possible sengs, see parameter
0x2634:001 (P420.01). ^ 415
Assignment of a trigger to bit 2 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
52 Operaon enabled
Conguring the network
General network sengs
184
