Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x2637:007
(P431.07)
Analog input 2: Dead band
(Analog input 2: AI2 dead band)
0.0 ... [0.0] ... 100.0 %
Oponal seng of a dead band that is placed symmetrically around the
frequency zero point.
•
The value set denes half the width of the dead band in [%].
•
Example: Seng 2 % results in a dead band of 4 %.
•
If the analog input value is within the dead band, the output value for
the motor control is set to "0".
0x2637:008
(P431.08)
Analog input 2: Monitoring threshold
(Analog input 2: AI2 monit.level)
-100.0 ... [0.0] ... 100.0 %
Monitoring threshold for analog input 2.
Trigger threshold for monitoring the analog input.
•
100 % ≡ 10 V (with conguraon as voltage input)
•
100 % ≡ 20 mA (with conguraon as current loop)
0x2637:009
(P431.09)
Analog input 2: Monitoring condion
(Analog input 2: AI2 error resp.)
Monitoring condion for analog input 2.
Trigger condion for monitoring the analog input.
•
If the selected condion is met, the "Error of analog input 2 acve
[82]" trigger is set to TRUE. The trigger can be assigned to a funcon
or a digital output.
•
If the selected condion is met for at least 500 ms, the error response
set in 0x2637:010 (P431.10) takes place.
•
If the trigger condion is met for at least 500 ms, the response set in
subindex 10 is eected.
0 Input value < trigger threshold Monitoring condion for analog input 2.
•
If the selected condion is met, the "Error of analog input 2 acve
[82]" trigger is set to TRUE. The trigger can be assigned to a funcon
or a digital output.
•
If the selected condion is met for at least 500 ms, the error response
set in 0x2637:010 (P431.10) takes place.
1 Input value > trigger threshold
0x2637:010
(P431.10)
Analog input 2: Error response
(Analog input 2: AI2 error resp.)
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 169
Error response for analog input 2.
•
The selected response takes place if the monitoring condion selected
in 0x2637:009 (P431.09) is met for at least 500 ms.
Associated error code:
•
28802 | 0x7082 - Error of analog input 2
3 Fault
0x2637:011
(P431.11)
Analog input 2: Min torque value
(Analog input 2: Min. torque)
-400.0 ... [0.0] ... 400.0 %
•
From version 03.00
Denion of the seng range for operang mode "MS: Torque mode".
•
100 % ≡ permissible maximum torque 0x6072 (P326.00)
•
Direcon of rotaon according to sign.
•
The standard setpoint source for operang mode 0x6060 (P301.00) =
"MS: Torque mode [-1]" is selected in 0x2860:003 (P201.03).
4Torque control w/ freq. limit ^ 153
0x2637:012
(P431.12)
Analog input 2: Max torque value
(Analog input 2: Max. torque)
-400.0 ... [100.0] ... 400.0 %
•
From version 03.00
Flexible I/O conguraon
Conguraon of analog inputs
Analog input 2
414
