Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x2302:002
(P511.02)
Acve CANopen sengs: Acve baud rate
(CANopen diag.: Acve baud rate)
•
Read only
Display of the acve baud rate.
0 Automac (from version 03.00)
1 20 kbps
2 50 kbps
3 125 kbps
4 250 kbps
5 500 kbps
6 800 kbps
7 1 Mbps
0x2307
(P515.00)
CANopen me-out status
(Time-out status)
•
Read only
Bit-coded status display of the CAN me monitoring funcons.
Bit 0 RPDO1-Timeout 1 ≡ RPDO1 was not received within the monitoring me or not with the
sync congured.
•
Status is reset automacally aer the RPDO has been received again.
•
Seng of monitoring me for RPDO1 in 0x1400:005 (P540.05).
Bit 1 RPDO2-Timeout 1 ≡ RPDO2 was not received within the monitoring me or not with the
sync congured.
•
Status is reset automacally aer the RPDO has been received again.
•
Seng of monitoring me for RPDO2 in 0x1401:005 (P541.05).
Bit 2 RPDO3-Timeout 1 ≡ RPDO3 was not received within the monitoring me or not with the
sync congured.
•
Status is reset automacally aer the RPDO has been received again.
•
Seng of monitoring me for RPDO3 in 0x1402:005 (P542.05).
Bit 8 Heartbeat-Timeout Consumer 1 1 ≡ within the "Heartbeat Consumer Time", no heartbeat telegram was
received from node 1 to be monitored.
•
Status can only be reset by mains switching or error reset.
•
"Heartbeat Consumer Time" seng in 0x1016:001 (P520.01).
Bit 9 Heartbeat-Timeout Consumer 2 1 ≡ within the "Heartbeat Consumer Time", no heartbeat telegram was
received from node 2 to be monitored.
•
Status can only be reset by mains switching or error reset.
•
"Heartbeat Consumer Time" seng in 0x1016:002 (P520.02).
Bit 10 Heartbeat-Timeout Consumer 3 1 ≡ within the "Heartbeat Consumer Time", no heartbeat telegram was
received from node 3 to be monitored.
•
Status can only be reset by mains switching or error reset.
•
"Heartbeat Consumer Time" seng in 0x1016:003 (P520.03).
Bit 11 Heartbeat-Timeout Consumer 4 1 ≡ within the "Heartbeat Consumer Time", no heartbeat telegram was
received from node 4 to be monitored.
•
Status can only be reset by mains switching or error reset.
•
"Heartbeat Consumer Time" seng in 0x1016:004 (P520.04).
0x2308
(P516.00)
CANopen status
(CANopen status)
•
Read only
Display of the current eldbus state
0 Inialisaon Fieldbus inialisaon acve.
•
The inialisaon is started automacally at mains connecon. During
this phase, the inverter us not involved in the data exchange process
on the CAN bus.
•
All CAN-relevant parameters are inialised with the saved sengs.
•
When the inialisaon process has been completed, the inverter
automacally adopts the "Pre-Operaonal" state.
1 Reset node "Reset Node" NMT command acve.
•
All parameters are inialised with the saved sengs (not only the
CAN-relevant parameters).
2 Reset communicaon "Reset Communicaon" NMT command acve.
•
Inialisaon of all CAN-relevant parameters with the values stored.
4 Stopped Only network management telegrams can be received.
5 Operaonal Parameter data and process data can be received. If dened, process
data is sent as well.
127 Pre-Operaonal Parameter data can be received, process data are ignored.
Diagnoscs and fault eliminaon
Diagnoscs parameter
Network diagnoscs
79
