Codes
Communication−relevant Lenze codes
14
l
137
EDSMF2178IB EN 3.0
C1871/C2371:
Emergency ID
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1871 − 22704 =
0x58B0
128 0 [1] 2047 FIX32
C2371 − 22204 =
0x56BC
This code contains the identifier with which the emergency telegram is sent.
Relation to CANopen
The object I−1014 (COB−ID Emergency Object) has a direct influence on this code. A value
written into the object is also transferred to code C1871/C2371.
C1872/C2372:
Emergency inhibit time
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1872 − 22703 =
0x58AF
0 0 [1 ms] 65535 FIX32
C2372 − 22203 =
0x56BB
This code contains the delay time for sending an emergency telegram.
Relation to CANopen
The object I−1015 (Inhibit Time EMCY) has a direct influence on this code. A value written
into the object is also transferred to code C1872/C2372.
