Process data transfer
Cyclic process data objects
Process data signals of Lenze controllers
9
l
63
EDSMF2178IB EN 3.0
Process data telegram from drive
The following data can be assigned to the PIW data (TPDOs):
Designation / variable name Explanation
Device status word (AIF1_DctrlStat) AIF word 1
AIF_nOutW1_a AIF word 2
AIF_nOutW2_a AIF word 3
AIF_nOutW3_a AIF word 4
AIF2_nOutW1_a AIF word 5
AIF2_nOutW2_a AIF word 6
AIF2_nOutW3_a AIF word 7
AIF2_nOutW4_a AIF word 8
AIF3_nOutW1_a AIF word 9
AIF3_nOutW2_a AIF word 10
AIF3_nOutW3_a AIF word 11
AIF3_nOutW4_a AIF word 12
AIF1_dnOutD1_p AIF double word 1
