14 Parameter reference
14.4 Table of attributes
112
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 11.0 EN · 04/2016 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Table of attributes
Code Name Index Data Access
dec hex DS DA Data type Factor R W CINH
C13000
IP address 11575 0x2D37 E 1 UNSIGNED_32 1
C13001
Subnet Mask 11574 0x2D36 E 1 UNSIGNED_32 1
C13002
Gateway address 11573 0x2D35 E 1 UNSIGNED_32 1
C13003
MAC-ID 11572 0x2D34 E 1 OCTET_STRING
C13010
Active IP Address 11565 0x2D2D A 4 UNSIGNED_8 1
C13011
Active Subnetwork Mask 11564 0x2D2C A 4 UNSIGNED_8 1
C13012
Active gateway address 11563 0x2D2B A 4 UNSIGNED_8 1
C13850
All words from drive to master 10725 0x29E5 A 32 UNSIGNED_16 1
C13851
All words from master to drive 10724 0x29E4 A 32 UNSIGNED_16 1
C13852
All words to the basic device 10723 0x29E3 A 32 UNSIGNED_16 1
C13853
All words to the basic device 10722 0x29E2 A 32 UNSIGNED_16 1
C13860
Settings 10715 0x29DB A 4 UNSIGNED_8 1
C13861
Bus status 10714 0x29DA E 1 UNSIGNED_16
C13862
Data cycles per second 10713 0x29D9 E 1 UNSIGNED_32
C13864
Active station name 10711 0x29D7 E 1 VISIBLE_STRING
C13865
Display: Last safety PRM data 10710 0x29D6 E 1 OCTET_STRING
C13867
Display: Most recent diagnostic data 10708 0x29D4 E 1 OCTET_STRING
C13879
Bus error 10696 0x29C8 E 1 UNSIGNED_32 1
C13880
Monitoring Reaction 10695 0x29C7 A 1 UNSIGNED_8 1
C13881
Response time when exiting
"Data_Exchange"
10694 0x29C6 E 1 UNSIGNED_16 1
C13882
Display: Monit. time: Watchdog 10693 0x29C5 E 1 UNSIGNED_32 1
C13885
Delete process data 10690 0x29C2 E 1 UNSIGNED_8 1
C13887
Suppression diagnostic message 10688 0x29C0 E 1 BITFIELD_8
C13899
Station name 10676 0x29B4 E 1 VISIBLE_STRING
C13900
Firmware Product Type 10675 0x29B3 E 1 VISIBLE_STRING
C13901
Firmware Compilation Date 10674 0x29B2 E 1 VISIBLE_STRING
C13902
Firmware Version 10673 0x29B1 E 1 VISIBLE_STRING
C13910
I&M1 system designation 10665 0x29A9 E 1 VISIBLE_STRING
C13911
I&M1 installation site 10664 0x29A8 E 1 VISIBLE_STRING
C13912
I&M2 installation date 10663 0x29A7 E 1 VISIBLE_STRING
C13913
I&M3 additional information 10662 0x29A6 E 1 VISIBLE_STRING
C13914
I&M4 signature code 10661 0x29A5 E 1 OCTET_STRING
C14000
IP address 10575 0x294F E 1 UNSIGNED_32 1
C14001
Subnet Mask 10574 0x294E E 1 UNSIGNED_32 1
C14002
Gateway address 10573 0x294D E 1 UNSIGNED_32 1
C14003
MAC-ID 10572 0x294C E 1 OCTET_STRING
C14010
Active IP Address 10565 0x2945 A 4 UNSIGNED_8 1
C14011
Active Subnetwork Mask 10564 0x2944 A 4 UNSIGNED_8 1
C14012
Active gateway address 10563 0x2943 A 4 UNSIGNED_8 1
C14850
All words from drive to master 9725 0x25FD A 32 UNSIGNED_16 1
C14851
All words from master to drive 9724 0x25FC A 32 UNSIGNED_16 1
C14852
All words to the basic device 9723 0x25FB A 32 UNSIGNED_16 1
C14853
All words to the basic device 9722 0x25FA A 32 UNSIGNED_16 1
C14860
Settings 9715 0x25F3 A 4 UNSIGNED_8 1
C14861
Bus status 9714 0x25F2 E 1 UNSIGNED_16
C14862
Data cycles per second 9713 0x29F1 E 1 UNSIGNED_32
C14864
Active station name 9711 0x25EF E 1 VISIBLE_STRING
C14865
Display: Last safety PRM data 9710 0x25EE E 1 OCTET_STRING
