97
The description of the above-mentioned table is as follows:
Item
Description
WAN
MAC Address
The MAC address of the WAN port.
IP Address
The IP address of the WAN port.
Subnet Mask
The Subnet Mask of the WAN port.
Packets Out/In
The total accumulated packets in/out through this WAN port since
the gateway boots up. The delta shows the difference between the
numbers from last time this Interface Status page is visited.
Bytes Out/In
The total accumulated bytes in/out through this WAN port since the
gateway boots up. The delta shows the difference between the
numbers from last time this Interface Status page is visited.
Number of Sessions
The sessions of WAN port.
Zone Wireless
General
Settings
MAC Address
The MAC address of the Wireless.
Band
The current Band setting of Wireless.
Channel
The current Channel setting of Wireless.
Transmit Power
The current Transmit Power setting of Wireless.
Zone - General
Mode
The operation mode of the zone.
MAC Address
The MAC address of the zone.
IP Address
The IP address of the zone.
Subnet Mask
The Subnet Mask of the zone.
Zone - DHCP
Status
Enable/disable stands for status of the DHCP server in this zone
WINS IP Address
The WINS server IP on DHCP server. N/A means that it is not
configured.
Start IP Address
The start IP address of the DHCP IP range.
End IP address
The end IP address of the DHCP IP range.
Lease Time
Minutes of the lease time of the IP address.
Zone - VAP
BSSID
The BSSID of this zone.
ESSID
The ESSID of this zone.
Security Type
The current security type of this zone.
Associated Clients
The number of associated clients in this zone.
