Lexmark E260 Service Manual

Diagnostic aids 3-1
4513-200, -220, -230
3. Diagnostic aids
Accessing service menus
There are two different test menus that can be accessed during POR to identify problems with the printer.
Printing menus
Print Configuration menus by pressing and holding Continue until all of the lights flash, then release the
button. The Configuration Mode Instruction page will print.
Print Diagnostic menus by pressing and holding Continue until all of the lights flash, then release the button.
The Ready/Data light will blink when the page is being formatted and printed.
Note: The Configuration Mode Instruction page and Diagnostic menu page in this manual are samples only and
may not match your specific machine.
Moving around the menu
“Configuration Menu printout” on page 3-2 and “Diagnostics mode printout sample” on page 3-3 are
similar to the instructions printed by following steps 1-3 above. These menu items are designated by the non-
indented items listed along the left edge of the page (Bottom as printed from printer). These items are also
unshaded.
• Press and release to move sequentially from one menu item to another.
• Press and hold to jump to home state (top four lights on).
• Press and release to move through the menu settings (indicated by and lights).
• This action rotates only through the possible settings of the selected menu item.
Configuration Menu 1. Turn off the printer.
2. Open the front access door.
3. Turn on the printer while pressing and
holding Continue .
4. Close the front access door once the Error
light displays.
The Configuration menu group contains a set
of menus, settings and operations which are
infrequently required by a user. Generally, the
options made available in this menu group are
used to configure a printer for operation.
See “Configuration menu selections” on
page 3-4.
Diagnostics Mode 1. Turn off the printer.
2. Open the front access door.
3. Turn on the printer while pressing and
holding Cancel .
4. Close the front access door once the Error
light displays.
The Diagnostic menu group contains the
settings and operations used while
manufacturing and servicing the printer.
See “Diagnostics mode selections” on
page 3-8.

Lexmark E260 Specifications

General

Color	No
Duplex printing	-
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (quiet mode)	48 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Memory upgrade	Yes GB
Mac compatibility	Yes
Standard input trays	2
Standard media sizes	10 envelop 7 3/4 envelop 9 envelop A4 A5 B5 envelop C5 envelop DL envelop A6 Executive Folio JIS-B5 Legal Letter Statement Universeel aan te passen afmetingen Oficio
Pallet weight (imperial)	656 lbs
Compatible operating systems	Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10, 11 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0, 11.1 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS SUSE Linux Enterprise Desktop 11 Debian GNU/Linux 5.0 Ubuntu 8.10, 9.04 Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Apple Mac OS X Apple Mac OS 9.2
Duty cycle letter size (maximum)	2500 pages per month
Copy speed (black, normal quality, A4)	33 cpm
Maximum duty cycle	50000 pages per month
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick B, CCC B, BSMI B, MIC, EK Mark, PSB
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Package weight	15700 g
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
Pallet dimensions (W x D x H)	1420 x 870 x 1219 mm
