Diagnostics information 2-67
4513-200, -220, -230
Printhead service check
Unexpected
characters print or
characters are
missing.
• Ensure correct printer driver is being used.
• Select hex trace mode to determine what the problem is.
• Restore factory defaults.
• Make sure the parallel cable or USB cable is firmly plugged in at the back of the printer.
Jobs are not printing,
and the error light is
on solid.
• The printer is waiting for an appropriate command.
• Make sure the toner cartridge assembly is installed properly.
• Make sure the printer front cover is closed.
While in PostScript 3
emulation, the printer
is flushing data
(Ready/Data and Error
lights are blinking).
• Ensure the correct PostScript driver is being used.
• The printer doesn’t have enough memory to print the job. Install more memory.
FRU Action
Printhead
Note: New printhead
must be aligned. See
“Adjustment
procedures” on
page 3-9.
Turn the printer off.
Disconnect the printhead cables from J8 and J100 on the controller board.
Turn the printer on with the front door closed.
On the controller board, verify +5 V dc on pin 10 at J8 and +5 V dc on pins 1 and 2 at J15.
Verify grounds on pins 2, 4, and 7 at J8 and on pin 4 at J15.
• If voltages or grounds are incorrect, then check the controller board. See “Controller
board service check” on page 2-52 for more information.
• If voltages are correct, then replace the printhead (comes with cables).
Print quality problems (Continued)
Problem Cause/action
To Next Page
