Lexmark E260 Service Manual

2-68 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Service software service check
There are different types of 900.xx errors that can occur. There may be a communication problem (Bad cable,
network connection, and so on) software issue, or a hardware problem with the controller board, or ISP (Internal
solutions port). The communication and software aspects should be checked first. Determine if the problem is
constant or intermittent. Use the troubleshooting procedure below to isolate the issue. Take any notes as
instructed. You will need that information in the event you need to contact your next level support.
Note: Before troubleshooting, determine the operating system used when the error occured. If possible
determine whether a PostScript or PCL file was sent to the device when the error occured. Ask the customer
which Lexmark Solutions applications are installed on the device.
Step Action and questions Yes No
1 POR the device.
Does the error reoccur?
Go to step 2. Problem resolved.
2
• Write down the exact 900.xx error
code displayed on the device.
• Turn the device off.
• Clear the print queues.
• Disconnect all communication cables,
and remove all memory options.
• Remove all ISP and modem cards.
• Restart the device into diagnostic
mode.
Does the 900.xx error reoccur during
startup?
Go to step 3. Go to step 6.
3
Check all the cables connected to the RIP
board for proper connectivity.
Are the cables properly connected?
Go to step 5. Go to step 4.
4
Properly connect the cables to the RIP
board. Restart the device into diagnostic
mode.
Does the 900.xx error reoccur during
startup?
Go to step 5. Go to step 6.
5
Replace the RIP board, and restart the
device.
Does this fix the problem?
Note: If an error, different from the
original 900.xx, is displayed, consult the
service check for that error.
Problem resolved. Go to step 31.
6
Print the following:
•Error log
• Menu settings page
• Network settings page
Does the 900.xx error reoccur while
these pages were printing?
Go to step 31. Go to step 7.

Lexmark E260 Specifications

General

Color	No
Duplex printing	-
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (quiet mode)	48 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Memory upgrade	Yes GB
Mac compatibility	Yes
Standard input trays	2
Standard media sizes	10 envelop 7 3/4 envelop 9 envelop A4 A5 B5 envelop C5 envelop DL envelop A6 Executive Folio JIS-B5 Legal Letter Statement Universeel aan te passen afmetingen Oficio
Pallet weight (imperial)	656 lbs
Compatible operating systems	Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10, 11 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0, 11.1 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS SUSE Linux Enterprise Desktop 11 Debian GNU/Linux 5.0 Ubuntu 8.10, 9.04 Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Apple Mac OS X Apple Mac OS 9.2
Duty cycle letter size (maximum)	2500 pages per month
Copy speed (black, normal quality, A4)	33 cpm
Maximum duty cycle	50000 pages per month
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick B, CCC B, BSMI B, MIC, EK Mark, PSB
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Package weight	15700 g
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
Pallet dimensions (W x D x H)	1420 x 870 x 1219 mm
