Lexmark E260 - Right Side Cover Assembly Removal

Repair information 4-53
4513-200, -220, -230
Right side cover assembly removal
Note: Leave the front cover closed when removing the right side cover assembly.
1. Remove the one screw (A) from behind the paper tray.
2. Remove the screw (B) from the bottom right side of the printer.
A
B
