Lexmark E260 - Fan Removal

4-16 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Fan removal
1. Remove the right side cover. See “Right side cover assembly removal” on page 4-53.
2. Disconnect the cable (A) from the controller board, and remove the two screws (B) holding the fan to the
right side frame.
3. Remove the fan.
A BB
