2-50 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Symptom tables
POST symptom table
Note: Investigate any displayed codes before proceeding with these symptoms. For example, a missing toner
cartridge will prevent POST from completing.
Symptom Action
The main motor, cooling fan, and fuser do not come
on.
See “Cover interlock switch service check” on page 2-53.
POST completes, except one or more lights do not
come on.
See “Operator panel service check” on page 2-57.
None of the lights come on. See “Operator panel service check” on page 2-57.
Main motor does not come on. See “Main motor service check” on page 2-55.
Fan does not come on. See “Cooling fan service check” on page 2-53.
Fuser does not cycle. See “Fuser service check” on page 2-54.
Fuser does not turn on and off. See “Fuser service check” on page 2-54.
The paper feed picks and tries to feed media. See “Paper feed service checks” on page 2-57.
