4-24 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Left side cover removal
Note:
• Leave the front door closed when removing the left side cover.
• Make sure that the fuser cables are out of the way when removing the left side cover.
1. Remove the paper tray.
2. Remove the screw (A) from the rear left side of the printer.
3. Remove the screw (B) and press the two latches (C) on the bottom of the left side cover.
