4-34 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Manual feed solenoid removal
1. Remove the right side cover. See “Left print cartridge guide” on page 4-23.
2. Remove the duplex. See “Duplex removal” on page 4-11.
3. Open the front access door, and place the printer on its right side.
Note: Be careful to not mar the finish of the printer.
4. Remove the two screws (A).
5. Disconnect the cable from J25 on the controller board, and remove the solenoid.
