Diagnostic aids 3-7
4513-200, -220, -230
Network
Use the network menu to change printer settings on jobs sent through a network port (either standard network or
network opt <x>).
Menu item Use setting to Values
NPA Mode Send print jobs to the printer and query printer status information
simultaneously.
Off
Auto (default)
MAC Binary PS Configure the printer to process Macintosh binary PostScript print
jobs.
Off—The printer filters
PostScript print jobs using
Standard protocol.
On—The printer processes raw
binary PostScript print jobs from
computers using the Macintosh
operating system. This setting
often causes Windows print jobs
to fail.
Auto (default)—The printer
processes print jobs from
computers using either
Windows or Macintosh
operating systems.
Set Card Speed Automatically detect the connection speed of the network.
This setting can be disabled to set the speed manually.
Auto (default)—the printer
detects current network speed.
10Mbps, half duplexforces the
printer to try to connect to the
network only at 10Mbps, half
duplex.
10Mbps, full duplex—forces the
printer to try to connect to the
network only at 10Mbps, full
duplex.
100Mbps, half duplex—forces
the printer to try to connect to
the network only at 100Mbps,
half duplex.
100Mbps, full duple—forces the
printer to try to connect to the
network only at 100Mbps, full
duplex.

Table of Contents

Other manuals for Lexmark E260

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark E260 and is the answer not in the manual?

Lexmark E260 Specifications

General IconGeneral
ColorNo
Duplex printing-
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print margins (top, bottom, right, left)4 mm
Print speed (black, normal quality, A4/US Letter)33 ppm
Maximum internal memory160 MB
Sound pressure level (printing)53 dB
Sound pressure level (quiet mode)48 dB
Total input capacity250 sheets
Maximum input capacity800 sheets
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Maximum print size216 x 297 mm
Paper tray media typesEnvelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 90 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Memory upgradeYes GB
Mac compatibilityYes
Standard input trays2
Standard media sizes10 envelop 7 3/4 envelop 9 envelop A4 A5 B5 envelop C5 envelop DL envelop A6 Executive Folio JIS-B5 Legal Letter Statement Universeel aan te passen afmetingen Oficio
Pallet weight (imperial)656 lbs
Compatible operating systemsLinpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10, 11 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0, 11.1 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS SUSE Linux Enterprise Desktop 11 Debian GNU/Linux 5.0 Ubuntu 8.10, 9.04 Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Apple Mac OS X Apple Mac OS 9.2
Duty cycle letter size (maximum)2500 pages per month
Copy speed (black, normal quality, A4)33 cpm
Maximum duty cycle50000 pages per month
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
CertificationFCC B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick B, CCC B, BSMI B, MIC, EK Mark, PSB
Power consumption (standby)12 W
Power consumption (printing)470 W
Power consumption (PowerSave)11 W
Pallet weight298000 g
Quantity per pallet18 pc(s)
Package weight15700 g
Standard interfacesParallel, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)406 x 370 x 260 mm
Pallet dimensions (W x D x H)1420 x 870 x 1219 mm
