4-8 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
Cover open sensor
1. Remove the right side cover. See “Right side cover assembly removal” on page 4-53.
2. Disconnect the cable (A) from the controller board.
3. Use a #1 Phillips screwdriver to remove the screw (B) holding the sensor.
4. Remove the cover open sensor.
