Lexmark E260 Service Manual

2-66 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
The printer is on and
indicates ready, but
nothing prints.
• Make sure the parallel or USB cable is not damaged and is firmly plugged into the
connector on the back of the printer.
• Make sure the toner cartridge assembly is installed properly.
• Press and release to print a menu settings page.
- If a menu settings page cannot be printed, then contact the next level of support.
- If a menu settings page can be printed, then the problem is one of the following:
• Computer
• Software program
• Cable
• (USB only) A failed controller board. Replace card.
Note: Test by unplugging USB and plugging it with the printer on. If the computer indicates
“unknown device,” then replace the controller board.
Toner Low light is on
and printing stops.
If a 3.5K or more page toner cartridge is being used and the Toner Low alarm is set to on,
then the printer stops printing until the toner cartridge is replaced.
The Error light alone is
on.
Make sure the printer front cover is closed.
The Toner Low light is
blinking, and the Error
light is on.
• Make sure the toner cartridge is installed correctly.
• Install a new toner cartridge.
The media skews or
buckles.
• Tray is overfilled or media is too loose.
• Don’t overfill Tray 1 or the optional Tray 2 (see media capacities in the media types and
sizes table in the User’s Guide).
• Make sure the paper guides are flush against the edges of the media.
The media sticks
together, resulting in
the printer feeding
multiple sheets.
• The friction between sheets is too high.
• Remove the media from Tray 1 or Tray 2, and fan it.
• Don’t overfill Tray 1 or the optional Tray 2 (see media capacities in the media types and
sizes chart in the User’s Reference).
The media fails to feed
from Tray 1.
• Frictional force between tires and media is less than resisting force.
• Remove the media from Tray 1, and fan it.
• Make sure Tray 1 is selected from the printer driver. Do not overfill the tray.
• Check the condition of the rubber on the paper feed rolls. Replace if worn or
contaminated.
• Verify that the ACM clutch is functioning correctly.
The media fails to feed
from the optional
Tray 2.
• Incorrect tray selection or inadequate picking force by tires.
• Make sure the correct tray and media type are selected from the driver.
• Make sure the tray is pushed all the way in.
• Remove the media from the optional Tray 2, fan it, and reload.
• Check the rubber on the paper feed tires for dirt or any other debris. Replace as
necessary.
• Check the paper path in the tray for burrs or debris that may hinder media movement.
• Make sure the media does not exceed the stack height indicator.
The Load Paper light
is on even though
there is media loaded
in the optional Tray 2.
• The input sensor does not sense media after picking.
• Make sure the tray is pushed all the way in.
•Press .
• Check the feed tires. (See two preceding actions.)
The printer does not
print after a paper jam
has been cleared.
• The printer is waiting on the next command.
• Clear all jams.
• Press and release , or open and close the printer cover to restart the printer.
• Make sure the toner cartridge assembly is installed properly.
Print quality problems (Continued)
Problem Cause/action

Lexmark E260 Specifications

General

Color	No
Duplex printing	-
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (quiet mode)	48 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Memory upgrade	Yes GB
Mac compatibility	Yes
Standard input trays	2
Standard media sizes	10 envelop 7 3/4 envelop 9 envelop A4 A5 B5 envelop C5 envelop DL envelop A6 Executive Folio JIS-B5 Legal Letter Statement Universeel aan te passen afmetingen Oficio
Pallet weight (imperial)	656 lbs
Compatible operating systems	Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10, 11 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0, 11.1 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS SUSE Linux Enterprise Desktop 11 Debian GNU/Linux 5.0 Ubuntu 8.10, 9.04 Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 x64 Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows 7 Apple Mac OS X Apple Mac OS 9.2
Duty cycle letter size (maximum)	2500 pages per month
Copy speed (black, normal quality, A4)	33 cpm
Maximum duty cycle	50000 pages per month
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick B, CCC B, BSMI B, MIC, EK Mark, PSB
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Package weight	15700 g
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
Pallet dimensions (W x D x H)	1420 x 870 x 1219 mm
