2-44 Lexmark™ E260, E260d, E260dn
4513-200, -220, -230
922.05 Did not roll over to a steady state control in time after the
hot roll lamp detection.
Replace the fuser. See “Fuser service check”
on page 2-54.
922.06 Hot roll did not reach the operating temperature in time
(new enhanced control).
922.07 Media reached fuser nip, and fuser is under temperature
922.08 Fuser warm-up failure (motor start condition)
922.09 Fuser warm-up failure (compression set)
922.20 Belt fuser failed to reach the preheat temperature for the
motor to start during warm-up.
922.21 Belt fuser was under temperature when the media
reached the fuser nip.
923.00 Fuser is over temperature.
923.01 Fuser is over temperature. This applies to the fuser and
belt fusers.
924.00 Open thermistor check.
924.01 Open thermistor check failure. This applies to the fuser
and belt fusers.
924.02 Open thermistor check failure. The ADC failed to
converge. Possible noisy thermistor signal. This applies
to the fuser and belt fusers.
925.xx Wrong fuser installed. The fuser type stored in the
cartridge ID does not match the actual fuser installed in
the printer.
Fan service errors
927.00 Service fan error Replace the fan. See “Cooling fan service
check” on page 2-53.
927.03 Main fan took too long to ramp up
927.04 Main fan is under speed or stalled during speed
adjustment state
927.05 Main fan overspeed during speed adjustment state.
927.06 Main fan capture data is invalid, and speed control is at
maximum in fan control idle state
927.07 Main fan capture data is invalid, and speed control is at
maximum in fan control adjustment state.
Printhead service errors
930.00 Wrong printhead installed Replace the printhead. See “Printhead service
check” on page 2-67.
931.00 No first hsync
Service error codes (9xx) (Continued)
Error Description Action
To Next Page
