4-32 Lexmark™ E260d, E260dn
4513-220, -230
6. Use a screwdriver to remove the e-clip (C) from the manual feed clutch.
7. Remove the manual feed clutch (D).
1. Remove the left side cover. See “Left side cover removal” on page 4-23.
2. Remove the duplex. See “Duplex removal” on page 4-11.
3. Open the front access door, and place the printer on its right side.
Note: Be careful to not mar the finish of the printer.
C
D
