Lexmark E260dn - Lower Front Cover Removal

Repair information 4-25
4513-220, -230
Lower front cover removal
1. Open the lower front cover.
2. Disconnect the manual feed plate notch (A) from the lower front cover.
3. Disconnect the lower front cover notches (B) from the front of the printer.
4. Remove the lower front cover.
A
