Lexmark E260dn User Manual

Diagnostic aids 3-1
4513-220, -230
3. Diagnostic aids
Accessing service menus
There are two different test menus that can be accessed during POR to identify problems with the printer.
Printing menus
Print Configuration menus by pressing and holding Continue until all of the lights flash, then release the
button. The Configuration Mode Instruction page will print.
Print Diagnostic menus by pressing and holding Continue until all of the lights flash, then release the button.
The Ready/Data light will blink when the page is being formatted and printed.
Note: The Configuration Mode Instruction page and Diagnostic menu page in this manual are samples only and
may not match your specific machine.
Moving around the menu
“Configuration Menu printout” on page 3-2 and “Diagnostics mode printout sample” on page 3-3 are
similar to the instructions printed by following steps 1-3 above. These menu items are designated by the non-
indented items listed along the left edge of the page (Bottom as printed from printer). These items are also
unshaded.
• Press and release to move sequentially from one menu item to another.
• Press and hold to jump to home state (top four lights on).
• Press and release to move through the menu settings (indicated by and lights).
• This action rotates only through the possible settings of the selected menu item.
Configuration Menu 1. Turn off the printer.
2. Open the front access door.
3. Turn on the printer while pressing and
holding Continue .
4. Close the front access door once the Error
light displays.
The Configuration menu group contains a set
of menus, settings and operations which are
infrequently required by a user. Generally, the
options made available in this menu group are
used to configure a printer for operation.
See “Configuration menu selections” on
page 3-4.
Diagnostics Mode 1. Turn off the printer.
2. Open the front access door.
3. Turn on the printer while pressing and
holding Cancel .
4. Close the front access door once the Error
light displays.
The Diagnostic menu group contains the
settings and operations used while
manufacturing and servicing the printer.
See “Diagnostics mode selections” on
page 3-8.

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
