Lexmark E260dn User Manual

2-28 Lexmark™ E260d, E260dn
4513-220, -230
Service codes
All service errors are indicated by all lights flashing as the primary notification or code. The secondary light
pattern indicates an area or function which has the error. Tertiary codes (shown on the following pages) indicate
specific device errors. When all lights flash, double-click to see the secondary code. Double-click again to
see the tertiary code. Double-click a third time to return to the primary light pattern.
In the following example:
• The primary light pattern indicates a service error (all flashing). Double-click for more information.
• The secondary light pattern indicates a fuser, toner sensor, or fan error. Double-click for more
information.
• The tertiary light pattern indicates the fan has stalled. Double-click again, and the original primary light
pattern will appear.
Note:
• The printer cannot directly determine that a fan has failed, but can sense the higher temperature at the
fuser or printhead.
• If data is sent to the printer and all lights flash simultaneously, and double-clicking does not produce a
secondary code, then there may be a code problem. Contact the next level of support.
Service primary code
When this code appears, double-click to reveal the secondary codes.
Service primary code
✷ Light blinking
Lights
Primary code for service errors
See service secondary error codes
✷ ✷ ✷ ✷ ✷ ✷
Secondary Codes
Primary Codes
Tertiary Codes
Double-
click
Double-
click

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
