Lexmark E260dn - Operator Panel Removal

4-44 Lexmark™ E260d, E260dn
4513-220, -230
Operator panel removal
1. Remove the nameplate. See “Nameplate removal” on page 4-43.
2. Remove the bezel. See “Bezel removal” on page 4-5.
3. Remove the four screws (A) from the display plate.
4. Lift the operator panel cover, and disconnect the operator panel cable (B).
5. Remove the operator panel.
A
B
