Lexmark E260dn User Manual

2-54 Lexmark™ E260d, E260dn
4513-220, -230
Black page
Note: Incorrect laser exposure or incorrect charging of the photoconductor causes an all black page. Always
verify the same results from a different toner cartridge assembly and developer before proceeding.
Heavy background
Poor development or poorly charged toner particles cause excessive background. This is more noticeable as
the toner cartridge nears end-of-life.
FRU Action
Toner electrodes (not a
FRU)
Check the three rearward electrodes below the toner cartridge assembly for contamination,
damage, or a short to ground. Correct as necessary.
Check continuity between the cable (DEV, TAR, and doctor blade) connection PCN3 and on
the contact tips below the toner cartridge assembly.
• If continuity fails, then call the next level of support.
LVPS/HVPS board
Controller board
Miscellaneous cables
With the printer off, disconnect the LVPS/HVPS cable from J502 on the controller board.
Turn the printer on, and verify +24 V dc on pins 17 and 19 of the cable.
Verify +5 V dc on pins 1, 3, 5, 13, and 15.
Verify ground on pins 10, 12,14, 16, and 18.
• If any of the values are incorrect, then replace LVPS/HVPS board.
• If the grounds are incorrect, then check ground paths.
• Check continuity in the cable. If the cable is bad, then call the next level of support.
• If the values are correct and the toner electrodes are good, then replace the controller
board.
• See the “LVPS/HVPS service check” on page 2-49 and the “Controller board
service check” on page 2-46, if necessary.
FRU Action
Toner cartridge (not a
FRU)
PC Kit (not a FRU)
Check the toner darkness setting in the driver. Try a lower setting.
Make sure the toner cartridge and PC Kit are correctly installed and the high voltage
contacts are clean.
If the toner cartridge and PC Kit are installed correctly, then try a new PC Kit first and then
toner cartridge.
LVPS/HVPS
Controller board
Check the contacts for correct installation and contamination where contact is made
between the toner cartridge assembly and spring contacts which connect to the LVPS/
HVPS board at PCN3. Clean as necessary.
If this does not correct the problem, then replace the following FRUs one at a time in the
order shown:
• LVPS/HVPS board (See “Black page” on page 3-54 for pin values.)
• Controller board

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
