2-40 Lexmark™ E260d, E260dn
4513-220, -230
Service error codes
Service error codes are generally non-recoverable except in an intermittent condition when the printer can be
put into POR to temporarily recover from the error condition.
Service error codes (9xx)
Error Description
Engine software service errors
902.xx Engine software error
DC pick motor errors
914.00 DC pick motor error
914.01 Lost encoder feedback
Transfer service errors
917.00 Transfer service error
917.01 Transfer servo result too low.
917.02 Immediate transfer servo indicates that the HVPS requires erase lamps.
Fuser service errors
920.00 Under temperature during steady state control.
920.01 Fuser took too long to heat up after transitioning to new enhanced mode.
920.02 Fuser fell too far below desired temperature while printing.
920.03 Fuser too cool while checking for slope change.
920.04 Fuser too cool when heating to desired temperature after slope change.
920.05 Fuser under temperature while printing
920.06 Fuser under temperature while printing
920.07 Fuser under temperature while printing
920.08 Fuser temperature did not increase after IR recovery.
920.20 Belt fuser under temperature during steady state control. This can occur in printing or standby modes.
921.00 Under temperature during standby control.
921.01 Fuser temperature did not reach standby temperature after two attempts
922.00 Fuser failed to ramp to target temperature
922.01 Fuser did not reach standby temperature in time (standby control)
922.02 Hot roll took too long to reach the beginning lamp detection temperature.
922.03 Hot roll reached final lamp detection temperature, but took longer than largest time in lookup table.
922.04 Hot roll timed out in trying to reach the final lamp detection temperature.
922.05 Did not roll over to a steady state control in time after the hot roll lamp detection.
922.06 Hot roll did not reach the operating temperature in time (new enhanced control).

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
