Diagnostics information 2-41
4513-220, -230
922.07 Media reached fuser nip, and fuser is under temperature
922.08 Fuser warm-up failure (motor start condition)
922.09 Fuser warm-up failure (compression set)
922.20 Belt fuser failed to reach the preheat temperature for the motor to start during warm-up.
922.21 Belt fuser was under temperature when the media reached the fuser nip.
923.00 Fuser is over temperature.
923.01 Fuser is over temperature. This applies to the fuser and belt fusers.
924.00 Open thermistor check.
924.01 Open thermistor check failure. This applies to the fuser and belt fusers.
924.02 Open thermistor check failure. The ADC failed to converge. Possible noisy thermistor signal. This applies to the
fuser and belt fusers.
925.00 Wrong fuser lamp installed.
925.01 Lamp detection performed and found error.
925.02 Too hot to do lamp detection, and NVRAM bit indicates previous wrong lamp detected.
Fan service errors
927.00 Service fan error
927.03 Main fan took too long to ramp up
927.04 Main fan is under speed or stalled during speed adjustment state
927.05 Main fan overspeed during speed adjustment state.
927.06 Main fan capture data is invalid, and speed control is at maximum in fan control idle state
927.07 Main fan capture data is invalid, and speed control is at maximum in fan control adjustment state.
Printhead service errors
931.00 No first hsync
931.01 No first hsync
932.00 Lost hsyncs
932.01 Lost hsyncs
933.01 Printhead boost signal failure
934.00 Mirror motor lost lock.
934.01 Mirror motor lost lock.
935.10 Printhead sweep error, swept through Hz range without finding the resonant frequency
935.11 Printhead sweep error, autosweep hw state
935.12 Printhead sweep error, coarse sweep state
935.13 Printhead sweep error, init fine sweep state
Service error codes (9xx) (Continued)
Error Description

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
