Lexmark E260dn User Manual

xvi Lexmark™ E260d, E260dn
4513-220, -230
Preface
This manual contains maintenance procedures for service personnel. It is divided into the following chapters:
1. General information contains a general description of the printer and the maintenance approach used to
repair it. Special tools and test equipment, as well as general environmental and safety instructions, are
discussed.
2. Diagnostic information contains an error indicator table, symptom tables, and service checks used to
isolate failing field replaceable units (FRUs).
3. Diagnostic aids contains tests and checks used to locate or repeat symptoms of printer problems.
4. Repair information provides instructions for making printer adjustments and removing and installing
FRUs.
5. Connector locations uses illustrations to identify the connector locations and test points on the printer.
6. Preventive maintenance contains the lubrication specifications and recommendations to prevent
problems.
7. Parts catalog contains illustrations and part numbers for individual FRUs.
Conventions
Note: A note provides additional information.
Warning: A warning identifies something that might damage the product hardware or software.
There are several types of caution statements:
CAUTION
A caution identifies something that might cause a servicer harm.
CAUTION
This type of caution indicates there is a danger from hazardous voltage in the area of the
product where you are working. Unplug the product before you begin, or use caution if the
product must receive power in order to perform the task.
CAUTION
This type of caution indicates a hot surface.
CAUTION
This type of caution indicates a tipping hazard.

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
