Repair information 4-41
4513-220, -230
Re-installation note:
Prop open the duplex door, and insert the hook end of the spring hook through the frame opening (C) from
the controller board side. Extend the hook until the sensor connector can be hooked.
Hook the spring hook (D) to the connector (E), and pull it through the opening.
Place the sensor into position, and reconnect the cable on the controller board.
Using the spring hook, be sure to reroute the cable through the three retainers (F) between the sensor and
side frame.
Note: If the cable is not properly installed in its retainers, then the loose cable will obstruct the paper path.
EDC
F

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark E260dn and is the answer not in the manual?

Lexmark E260dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)33 ppm
Duplex print speed (black, normal quality, A4/US Letter)17 ppm
Internal memory32 MB
Processor frequency400 MHz
Maximum internal memory160 MB
Sound pressure level (printing)53 dB
Sound pressure level (duplex printing)52 dB
Total input capacity250 sheets
Maximum input capacity800 sheets
Multi-Purpose tray input capacity1 sheets
Networking featuresFast Ethernet
Standard input trays2
Pallet weight (imperial)656 lbs
Compatible operating systemsMicrosoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)33 cpm
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesEnvelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)B5
Maximum duty cycle50000 pages per month
Power consumption (standby)12 W
Power consumption (printing)470 W
Power consumption (PowerSave)11 W
Pallet weight298000 g
Quantity per pallet18 pc(s)
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
CertificationFCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)370 x 260 x 406 mm
