Lexmark E260dn User Manual

2-38 Lexmark™ E260d, E260dn
4513-220, -230
200.40 Invalid sample count in auto alignment.
200.41 ZW adder out of range in auto alignment.
200.42 Rogue sheet is at the manual feed sensor while flushing the paper path prior to declaring MPF source empty.
200.43 The paper is at the input sensor before interruption occurs. Possible causes include bouncy sensor or an
exceptionally small gap, perhaps due to the paper being pre-staged in the source tray.
201.00 Paper jam between input and exit sensor
201.01 Transport motor identification failed to identify either motor after two tries.
201.02 Exit sensor never made by leading edge of page. Also known as internal jam.
201.03 Video never started on the page at the input sensor within two inches after hitting the input sensor
201.05 Restart attempted after an internal jam without the cover open/close event. It is likely that the jam was never
cleared.
201.25 Exit sensor never made by leading edge of media when feeding out the media that was detected during warm-
up.
201.26 Page at fuser nip before fuser started ramping toward desired temperature. Indicates code may be receiving
more hall interrupts than intended
201.27 Page at fuser nip before fuser reached acceptable operating temperature. Page arrived at fuser earlier than
expected, so it was probably staged
202.00 Paper jam around exit sensor.
202.01 Exit sensor never broke on the trailing edge of the sheet at the exit sensor.
202.02 Exit sensor never broke from sheet ahead of page heading toward the exit sensor.
202.06 Exit sensor bounced
202.13 Exit sensor covered, media not expected (media not in machine during warm-up)
202.25 Exit sensor never broke from the sheet ahead of the page heading toward the exit sensor when feeding out the
media detected during warm-up.
202.26 Trailing edge never cleared exit sensor when feeding out media that was detected during warm-up.
202.32 Long media or shingled multi feed stopped before sending to duplex.
231.00 Duplex jam while reversing into the device
231.01 Duplex sensor never made by leading edge reversing into the duplex.
231.02 Bouncy duplex sensor never made.
232.00 Duplex jam while staging in the device
232.01 Duplex sensor never broke by the sheet ahead after reversing into the duplex.
232.02 Page in duplex ahead of current reversing page never staged.
233.00 Duplex jam while picking from the device
233.01 Page in duplex never picked.
233.02 Feed error picking from the duplex.
Paper jam error codes (200-series) (Continued)
Error Description

Lexmark E260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Internal memory	32 MB
Processor frequency	400 MHz
Maximum internal memory	160 MB
Sound pressure level (printing)	53 dB
Sound pressure level (duplex printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Multi-Purpose tray input capacity	1 sheets
Networking features	Fast Ethernet
Standard input trays	2
Pallet weight (imperial)	656 lbs
Compatible operating systems	Microsoft Windows Server 2000/2003 Microsoft Windows Vista/XP Apple Mac OS X Apple Mac OS 9.x Linux
Copy speed (black, normal quality, A4)	33 cpm
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	50000 pages per month
Power consumption (standby)	12 W
Power consumption (printing)	470 W
Power consumption (PowerSave)	11 W
Pallet weight	298000 g
Quantity per pallet	18 pc(s)
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	370 x 260 x 406 mm
